XCMG Official XE1300C Crawler Excavator for sale
XE1300C Crawler Excavator
1、The overall layout and the axle load distribution aremore reasonable to achieve better traveling stability and the maximum travelingspeed is up to 40km/h to realize faster site transfer speed.
2、The domestic leading hydraulic system distributiontechnology features high energy-saving and efficiency.
3、The highest breakout force on the loading end is leadingthe industry by 15%~20% compared with like models.
4、The advanced structure and hinge points on the diggingend and the industry’s largest rotating angle of thebucket ensure strong soil holding capacity.
| Description
| Unit
| Parameter value
|
| Operating weight
| kg
| 125000
|
| Bucket capacity
| m³
| 5.0 -6.7
|
| Engine
| Model
| Engine
| QSK23-C760
|
| Style
| Direct injection
| ---
| √
|
| Four strokes
| ---
| √
|
| Water cooling
| ---
| √
|
| Turbo-charging
| ---
| √
|
| Air to air intercooler
| ---
| √
|
| No. of cylinders
| ---
| 6
|
| Output power
| kW/ r/min
| 567/1800
|
| torque/speed
| N.m
| 3468/1350
|
| Displacement
| L
| 23.15
|
|
Main performance
| Travel speed(H/L)
| km/h
| 2.7/1.6
|
| Gradeability
| %
| 70
|
| Rotary speed
| r/min
| 4.8
|
| Ground pressure
| kPa
| 156
|
|
Hydraulic system
| Main pump
| --
| 3
|
| Rated flow of main pump
| L/min
| 3×531
|
| Pressure of travel system
| MPa
| 34.3
|
| Pressure of pilot system
| MPa
| 3.9
|
| Oil Capacity
| Fuel tank capacity
| L
| 1485
|
|
Appearance size
(Standard configuration 7.8m boom)
| Overall length
| mm
| 14640
|
| Overall width
| mm
| 6430
|
| Overall height
| mm
| 5585
|
| Track gauge
| mm
| 4000
|
| Track width
| mm
| 700
|
| Minimum ground clearance
| mm
| 740
|
| Track height
| mm
| 1674
|
| Track length
| mm
| 6500
|
| Wheel base of track
| mm
| 5050
|
| Ground clearance of counterweight
| mm
| 1885
|
| Distance from the tail to the rotary center
| mm
| 4740
|
| Swing radius of rear-end
| mm
| 4870
|
|
Appearance size
(Standard configuration 9.1m boom)
| Overall length
| mm
| 15940
|
| Overall width
| mm
| 6160
|
| Overall height
| mm
| 5585
|
| Track gauge
| mm
| 4000
|
| Track width
| mm
| 700
|
| Minimum ground clearance
| mm
| 740
|
| Track height
| mm
| 1674
|
| Track length
| mm
| 6500
|
| Wheel base of track
| mm
| 5050
|
| Ground clearance of counterweight
| mm
| 1885
|
| Distance from the tail to the rotary center
| mm
| 4740
|
| Swing radius of rear-end
| mm
| 4870
|
|
Working scope
(Standard configuration 7.8m boom)
| Max. digging height
| mm
| 13340
|
| Max. dumping height
| mm
| 8580
|
| Max. digging depth
| mm
| 7340
|
| Max. vertical wall digging depth
| mm
| 5670
|
| Max. ground digging radius
| mm
| 13640
|
|
Working scope
(Standard configuration 9.1m boom)
| Max. digging height
| mm
| 13390
|
| Max. dumping height
| mm
| 8800
|
| Max. digging depth
| mm
| 8700
|
| Max. vertical wall digging depth
| mm
| 8570
|
| Max. ground digging radius
| mm
| 7640
|
