G15ZZ Technical Specifications:
|
Type
|
Model
|
Unit
|
G15ZZ
|
|
Performance of mixing drum
|
Geometric volume
|
m³
|
23.5
|
|
Mixing volume
|
m³
|
15
|
|
Maximum diameter of drum body
|
mm
|
2432
|
|
Length of mixing drum
|
mm
|
7009
|
|
Angle of inclination
|
°
|
10
|
|
Rotating speed
|
r/min
|
0~14
|
|
Charge speed
|
m³/min
|
≥3
|
|
Discharge speed
|
m³/min
|
≥2
|
|
Residue ratio of discharge
|
%
|
<0.7
|
|
Range of slump
|
cm
|
5~21
|
|
Hydraulic system
|
Oil pump
|
|
international brand
|
|
Motor
|
|
international brand
|
|
Reduction gears
|
|
international brand
|
|
Hydraulic circuit
|
|
Closed type
|
|
Water supply
|
water tank capacity
|
L
|
450
|
|
Way of water supply
|
|
Pneumatic
|
|
Complete machine
|
Brand of chassis
|
|
Sinotruck
|
|
Chassis model
|
|
ZZ1317N3667C1
|
|
Type of driving
|
|
Left-hand drive
|
|
Curb weight
|
kg
|
17600
|
|
maximum gross weight
|
kg
|
31000
|
|
Type of drive
|
|
8×4
|
|
Wheel base
|
mm
|
1800+3600+1350
|
|
Tyre
|
|
12.00R20
|
|
Means of power takeoff
|
|
Power takeoff by flywheel
|
|
Notice model
|
|
XZJ5311GJB1
|
|
External dimensions
|
(length×width×height)mm
|
11352×2500×4000
|
|
Engine
|
Model
|
|
WD615.96E
|
|
Rated power
|
Kw/r/min
|
276
|
|
Displacement
|
L
|
9.726
|
|
Emission standard
|
|
GB III
|
& Due to improvements made to the product, data herein is subject to change without notice.
& Affected by the reproduction conditions, the pictures and data differ somewhat from the actual machine
