SQ10ZK3Q Technical Specifications:
|
Model
|
SQ10ZK3Q
|
Unit
|
|
Max Lifting Moment
|
20
|
t.m
|
|
Max Lifting Capacity
|
10000
|
kg
|
|
Recommend Power Needed At Recommend Oil Flow
|
28
|
kw
|
|
Max Oil Flow of Hydraulic System
|
40
|
L/min
|
|
Rated Pressure Of Hydraulic System
|
28
|
MPa
|
|
Oil Tank Capacity
|
160
|
L
|
|
Rotation Angle
|
(360°)All Rotation
|
?
|
|
Crane Weight
|
3477
|
kg
|
|
Installation Space
|
1150
|
mm
|
|
Choice of Chassis
|
DFL1250A9 ; CA1240PK2L7T4EA81; HFC1202KR1K3; EQ5201GFJ6; CA1200PK2L7T3EA80; BJ1317VNPJJ-S5; BJ5253ZKPJJ; CA1253P7K2L11T1E ; EQ1252GFJ; DFL1253AX;
|
|
SQ10ZK3Q Lifting capability diagram
|
|
Working radius (m)
|
2
|
4.17
|
5.99
|
7.87
|
9.75
|
|
Lifting capacity (kg)
|
10000
|
4600
|
3050
|
2280
|
1700
|
& Due to improvements made to the product, data herein is subject to change without notice.
& Affected by the reproduction conditions, the pictures and data differ somewhat from the actual machine
