SQ8ZK3Q Technical Specifications:
|
Model
|
SQ8ZK3Q
|
Unit
|
|
Max Lifting Moment
|
16
|
t.m
|
|
Max Lifting Capacity
|
8000
|
kg
|
|
Recommend Power Needed At Recommend Oil Flow
|
28
|
kw
|
|
Max Oil Flow of Hydraulic System
|
40
|
L/mi
|
|
Rated Pressure Of Hydraulic System
|
28
|
MPa
|
|
Oil Tank Capacity
|
160
|
L
|
|
Rotation Angle
|
(360°)All Rotation
|
?
|
|
Crane Weight
|
2970
|
kg
|
|
Installation Space
|
1150
|
mm
|
|
Choice of Chassis
|
CA1176PK2L9T3A95 ;CA1170PK2L7T3EA80; CA1240PK2L7T4EA81; HFC1202KR1K3;EQ5161GFJ7;BJ1317VNPJJ-S5; EQ5201GFJ6;CA1200PK2L7T3EA80; LZ1160LCMTDFL1250A9;BJ5317ZNPJJ-S;CA1253P7K2L11T1E ;EQ1252GFJ;ND1255B50J
|
|
SQ8ZK3Q Lifting capability diagram
|
|
Working radius (m)
|
2
|
4.175
|
5.995
|
7.785
|
9.755
|
|
Lifting capacity (kg)
|
8000
|
3700
|
2400
|
1700
|
1250
|
& Due to improvements made to the product, data herein is subject to change without notice.
& Affected by the reproduction conditions, the pictures and data differ somewhat from the actual machine
