RP753 Paver
Drive left and right independent drive, microcomputer control, constantspeed automatic control technology for paving speed, SC7H190 water-cooledsupercharged engine of Shangchai (optional Dalian Deutz engine BF6M2012), usinga three-in-one powerful composite radiator, left and right transmission, andmaterial distribution Four sets of independent hydraulic system transmissions,high wear-resistant alloy material for the material-discharging blades,imported wear-resistant steel plate for the feeding floor and the screed bottomplate, and the left and right material-dispensing devices can be easily movedup and down to accommodate different paving thicknesses. A horizontal automaticleveling system ensures the flatness of the paving. Centralized lubrication system.
Description | Unit | Parameter value | |
Dimension | | 6545×2880×4000 | |
|
|
Weight | kg | 18700-25000 | |
Driving speed | km/h | 0-3 | |
Basic pave width | m | 2.5-7.5 | |
Maximum pave width | m | 7.5 | |
Maximum layer thickness | mm | 350 | |
Maximum paving speed | m/min | 20 | |
Hopper capacity | kg | 14000 | |
Maximum laydown rate | t/h | 600 | |
Rate power | kw/rpm | 140/2000 | |
