XG600D Underground Diaphragm Wall Hydraulic Grab The specific extra-wide chassis manufactured with XCMG’smature technologies, having large swiveling bearing, provides super stability.
Double winch and single row rope construction extendthe life-span of the steel rope, reduce the construction cost. The controlsystem equipped with an ensures the accurate synchronization of double winchesreduces the frequency of synchronized adjustment and increases the constructionefficiency.
Equipped with advanced inclinometer, which can providethe grab adjustment and fall down protection function, it can record and memorythe locus grab, and draw the wall curve. This can effectively guarantee thewall precision.
With the load-sensing control, the hydraulic systemcan effectively increase the utilization rate of system resources and also theconstruction efficiency.
With quick plug connectors used in the circuit ofcontrol system, the fault rate is reduced and accordingly the time consumed forfault detection is shortened
| Type
| Date
|
| Wall depth
| 105 m
|
| Max. Pull-down piston pull
| 2×300 kN
|
| Max. pull/push speed
| 40 m/min
|
| Grab opening time
| 5.0 sec
|
| Grab closing time
| 5.4 sec
|
| Hydraulic system pressure
| 33 MPa
|
| Work radius
| 4600~5800 mm
|
| Engine Model
| CUMMINS QSM11
|
| Engine Rated Power
| 298/2100 kW/rpm
|
| Max. traveling speed
| 1.5 km/h
|
| Max. grade ability
| 35%
|
| Min. Clearance
| 450 mm
|
| Track shoe width
| 800 mm
|
| Distance between tracks
| 3500~4900 mm
|
| Dimension (Working condition)
| 11650×4900×18910 mm
|
| Dimension (Transportation condition)
| 16120×3500×3800 mm
|
| Overall drilling weight
| 120 t
|
