XZJ5184GQXD5 cleaning vehicle has independent high and low pressurewater system. High pressure water can clean road surface, curb, sidewalk andguardrail isolation area; high pressure spray gun can also clean road signs,billboards and elevated roads. The spray system features powerful spraydusting, aerosol disinfection and air humidity adjustment. The low-pressurewaterway system can be used for watering, dusting, and greening.
| Project
| Content
| Parameter
|
|
Chassis parameters
| Model
| EQ1181LJ9BDE
|
| Power Kw
| 132/136/155
|
| Wheelbase (mm)
| 4500
|
| Front overhang / rear overhang (mm)
| 1230/2320
|
|
Vehicle parameters
| Maximum total mass (kg)
| 18000
|
| Length × width × height (mm)
| 8050×2520×2910
|
| Curing quality (kg)
| 7460
|
|
Work performance parameter
| Effective volume of tank (m3)
| 10.8
|
| Working speed (km/h)
| 5~20
|
| Sprinkling width (m)
| ≥16
|
| Flush width (m)
| ≥24
|
| Nozzle Flush System Pressure (kPa)
| ≥300
|
| Gun flushing flow rate (L/min)
| ≥60
|
| Spray gun range (m)
| ≥36
|
| Self-priming height (m)
| 6.5
|
