XCMG Official 53m Elevating Aerial Work Platform Fire Truck DG53C/C2 for sale

1.The machine has the function of high platform fire truck and high spray car, which can not only rescue the emergency, but also put out the fire (with water pump and water gun).
2.The machine is advanced in technology and reliable in quality, and its main safety performance reaches (or exceeds) the level of similar products abroad.
3.The whole machine adopts electro-hydraulic proportional control, with hydraulic transmission, has stable and reliable operation, and is easy to operate.
4.With 5 telescopic arms and 1 curved arm
The machine has 5 synchronous adjustable telescopic arms (The telescopic mechanism is the first grade oil cylinder plus chain drive, realizing synchronous expansion).The telescopic arm can vary in the range of -3 degrees to 80 degrees. Crank arm can achieve 0 ° to 180 ° amplitude. The cross section is box shaped and is made of high strength steel.
5.Smooth movement
The rotary mechanism adopts planetary gear reducer and long closed brake, with quantitative motor driving tooth outside single ball slewing bearing. The hydraulic system is equipped with a buffer valve, which can achieve stable and reliable starting and braking, and has good micro-dynamic performance.
Fire pump:
Rated flow: 65 L/s
Rated pressure: 1.0mpa
Monitor:
Model: PSKY50 + akron1000-5055
Rated flow rate: 50 L/s
Rated pressure: 1.0mpa
Range: 65 m

Main Performance Parameters of Vehicle
Boundary dimension: (Length × width × height)	13430×2500×3990mm
Full mass	32900kg
Maximum speed	≥85km/h (electric speed limit)
Minimum turning diameter	≤24m
Approach angle	≥16°
Departure angle	≥9°
Maximum gradeability	≥25%
Outrigger span	Longitudinal span	6450mm
	Horizontal span	6000mm
Work platform load	400kg
Maximum working height	53m
Maximum working radius	17m
Elevating angle of boom	The elevating angle of telescopic boom is -3°~80°
	The elevating angle of folding boom and telescopic boom is 0°-175°
Rotation scope	360° full-rotation
Spread time of outrigger	≤30s
Time for lifting the boom to rated height and rotating 90°	≤180s
Maximum slewing speed	0.5~1r/min
FIRE FIGHTING PUMP	Rated flow	≥65 L/s
	Rated pressure	≥1.0MPa
Fire fighting gun	Model	PSKY50+akron1000-5055
	Rated flow	50 L/s
	Rated pressure	1.0MPa
	Range	65m
