XCMG Official XE335C Crawler Excavator for sale
XE335C Crawler Excavator
1、The overall layout and the axle load distribution aremore reasonable to achieve better traveling stability and the maximum travelingspeed is up to 40km/h to realize faster site transfer speed.
2、The domestic leading hydraulic system distributiontechnology features high energy-saving and efficiency.
3、The highest breakout force on the loading end is leadingthe industry by 15%~20% compared with like models.
4、The advanced structure and hinge points on the diggingend and the industry’s largest rotating angle of thebucket ensure strong soil holding capacity.
| Description
| Unit
| Parameter value
|
| Operating weight
| kg
| 33800
|
| Bucket capacity
| m³
| 1.4
|
| Engine
| Model
| Engine
| ISUZU
AA-6HK1XQP
|
| Style
| Direct injection
| ---
| √
|
| Four strokes
| ---
| √
|
| Water cooling
| ---
| √
|
| Turbo-charging
| ---
| √
|
| Air to air intercooler
| ---
| √
|
| No. of cylinders
| ---
| 6
|
| Output power
| kW/ r/min
| 190.5/2000
|
| torque/speed
| N.m
| 872.8/1700
|
| Displacement
| L
| 7.79
|
|
Main performance
| Travel speed(H/L)
| km/h
| 5.5/3.3
|
| Rotating speed
| r/min
| 9.7
|
| Gradeability
| °
| ≤35
|
| Ground pressure
| kPa
| 66
|
| Bucket digging force
| kN
| 263
|
| Arm digging force
| kN
| 225
|
| Maximum traction
| kN
| 261
|
|
Hydraulic system
| Main pump
| --
| 2
|
| Rated flow of main pump
| L/min
| 2×280
|
| Pressure of prime valve
| MPa
| 34.3/37
|
| Pressure of travel system
| MPa
| 34.3
|
| Pressure of swing system
| MPa
| 26.5
|
| Pressure of pilot system
| MPa
| 3.9
|
| Oil Capacity
| Fuel tank capacity
| L
| 630
|
| Hydraulic tank capacity
| L
| 350
|
| Engine oil capacity
| L
| 28
|
|
Appearance size
| Overall length
| mm
| 11388
|
| Overall width
| mm
| 3190
|
| Overall height
| mm
| 3515
|
| Width of platform
| mm
| 2950
|
| Length of crawler
| mm
| 4725
|
| Overall width of chassis
| mm
| 3190
|
| Width of crawler
| mm
| 600
|
| Wheel base of crawler
| mm
| 3183
|
| Crawler gauge
| mm
| 2590
|
| Clearance under counterweight
| mm
| 1700
|
| Min. ground clearance
| mm
| 495
|
| Min. tail swing radius
| mm
| 3570
|
|
Working scope
| Max. digging height
| mm
| 10074
|
| Max. dumping height
| mm
| 6898
|
| Max. digging depth
| mm
| 6972
|
| Max. digging depth at the range of level 8 feet
| mm
| 6728
|
| Max. vertical wall digging depth
| mm
| 5366
|
| Max. digging reach
| mm
| 10650
|
| Min. swing radius
| mm
| 4424
|
|
Worker
| Standard
| Length of boom
| mm
| 6400
|
| Length of arm
| mm
| 2670
|
| Bucket capacity
| m³
| 1.4
|
| Length of arm
| m³
| 2900
|
| Bucket capacity
| m³
| 1.6 /1.4
|
