XP303S tire roller usespneumatic tires as the working device to compact the ply material, and ismainly applied to the compaction operations of asphalt pavement, foundationlayer, sub-base layer, dam and filling works, etc. It is to build high-gradehighways, Ideal compaction equipment for airports, ports, embankments andindustrial construction sites.

Description		Unit	Parameter value
Minimum operating mass		kg	15000
Maximum operating mass		kg	30300
Mass of added heavy water		kg	650
Added mass		kg	14550
Compacting width		mm	2360
Overlap amount of tires		mm	65
Ground pressure		kPa	200-545
Minimum turning radius		mm	7620
Swing amount of front wheel		mm	±50
Minimum ground clearance		mm	300
Theoretical gradeability		%	20
Wheelbase		mm	3840
Driving speed	I	km/h	0-8
	II		0-13
Model of diesel engine			SC7H180.2G3
Rated power		kw	132
Rated speed		r/min	1800
Rated fuel oil consumption		g/kW·h	≤233
Tire specification			13/80-20Ⅱ
Tread pattern			Smooth tread tire
Number of tires			4 front tires and 5 rear tires
Length (standard for sprinkling water)		mm	4925
Length (optional for spraying oil)		mm	5015
Width		mm	2530
Height		mm	3370
Capacity of fuel tank L		L	170
Capacity of water tank L		L	650
