Technical Specifications

Main technical data in travel configuration
Category	Item		Unit	Parameter
Dimension	Overall length		mm	11380
	Overall		mm	3900
	Overall		mm	2500
	Wheel base	Axles 1 and 2	mm	4500
		Axles 2 and 3	mm	1350
	Tread	Front axle	mm	2053
		Rear axle	mm	1802
Weight	Weight with full load		kg	23950
	Axle load	Front axle	kg	6450
		Dual rear axles	kg	17500
Travel performance	Max. travel speed		km/h	85
	Min. turning diameter		m	≤24
	Approach angle		°	16
	Departure angle		°	10
	Braking distance(at 30km/h)		m	≤10
	Min. ground clearance		mm	204
	Max. gradeability		%	≥25
Main technical data for operation
Main performance	Rated working		m	32
	Rated load		kg	400
	Max. working radius (Full extending/semi-extending)		m	19/15
	Outrigger span(longitudinal×lateral)		m	6650×5800
	Elevating range		°	?3~80
Working speed	Boom deploying time		S	≤130
	Outrigger extending time		S	≤40
	Slewing speed		r/min	0~1.5
Fire-fighting performance	Water monitor rated flow		L/s	50
	Water monitor rated pressure		MPa	≤1.0
	Water monitor rated reach		m	≥65
	Fire pump rated flow		L/s	50
	Fire pump rated outlet pressure		MPa	1.8

& Due to improvements made to the product, data herein is subject to change without notice.
& Affected by the reproduction conditions, the pictures and data differ somewhat from the actual machine
