Technical Specifications

Dimensions	Unit
Overall length	Mm	14155
Overall	Mm	2800
Overall	Mm	3675
Weight
Dead weight in travel state	Kg	44490
1st.2nd axle load	Kg	9245
3rd.4th axle load	Kg	26000
Power
Carrier engine		WD615.338
Engine rated output	Kw(r/min)	276/2200
Travel
Max.travel speed	Km/h	80
Min. turning diameter	M	24
Min. ground clearance	Mm	324
Approach angle	?	21
Departure angle	?	14
Max. gradeability	%	40
Fuel consumption of per 100km	L	45
Lifting performance
Max. total rated lifting capacity	T	70
Min. rated working radius	M	3
Turning radius at swing table tail	Mm	3857
Base boom max. load moment	Kn.m	2676
Base boom	M	11.8
Full-extend boom	M	45
Full-extend boom+Jib	m	61
Outrigger longitudinal distance span	M	6.1
Outrigger lateral distance span	M	7.3
Working speed
Boom elevating time	S	60
Boom telescoping time	S	150
Max. slewing speed	r/min	2
Main winch max. speed(single line)	m/min	130
Auxiliary winch max.speed(single line)	m/min	108

& Due to improvements made to the product, data herein is subject to change without notice.
& Affected by the reproduction conditions, the pictures and data differ somewhat from the actual machine
