Technical Specifications
|
Item
|
Parameter
|
|
Rated bucket capacity
|
3.5m³
|
|
Rated load
|
6000kg
|
|
Operating weight
|
20000kg
|
|
Min. clearance
|
467mm
|
|
Max. traction
|
171kN
|
|
Max.drawing force
|
201kN
|
|
Boom lifting time
|
5.7s
|
|
Total time of three devices
|
10.9s
|
|
Engine
|
Model
|
Cummins QSC8.3
|
|
Type
|
6-cylinder, 4-stroke, electronic injection, turbocharging
|
|
Rated power
|
179kW
|
|
Rated rotary speed
|
2200r/min
|
|
Travel speed
|
Forward/Backward I Gear
|
6/6km/h
|
|
|
Forward/Backward II Gear
|
11/11km/h
|
|
|
Forward/Backward III Gear
|
22/22km/h
|
|
|
Forward IV Gear
|
36km/h
|
|
Tyre model
|
23.5-25
|
& Due to improvements made to the product, data herein is subject to change without notice.
& Affected by the reproduction conditions, the pictures and data differ somewhat from the actual machine
