Technical Specifications

		Unit	XZJ5110GLQ
Spraying		mm	200-6000
Asphalt spraying dosage		kg/m2	0.2~3.0
Asphalt tank capacity		L	5000
Max.total weight		t	11
Spraying precision			±1.5%
Chassis	Model		EQ1110TJ12D5
	Engine power	kw	100
	Site transfer speed	km/h	≥80
Spraying medium			Emulsified asphalt, hot (modified) asphalt, Kerosene cutback asphalt
Heating			Diesel burner
Fuel tank		L	100
Electrical system		V	24
Dimension			7445×2285×2550

& Due to improvements made to the product, data herein is subject to change without notice.
& Affected by the reproduction conditions, the pictures and data differ somewhat from the actual machine
