Technical Specifications
|
Model
|
SQ8SK3Q
|
Unit
|
|
Max Lifting Capacity
|
8000
|
kg
|
|
Max Lifting Moment
|
20
|
T.M
|
|
Recommend Power
|
28
|
kw
|
|
Max Oil Flow of Hydraulic System
|
55
|
L/min
|
|
Max Pressure of Hydraulic System
|
27
|
MPa
|
|
Oil Tank Capacity
|
160
|
L
|
|
Rotation Angle
|
All Rotation
|
|
Crane Weight
|
3300
|
kg
|
|
Installation Space
|
1200
|
mm
|
|
Choice of Chassis
|
CA1176PK2L9T3A95 ; CA1170PK2L7T3EA80; CA1240PK2L7T4EA81; HFC1202KR1K3; EQ5161GFJ7; BJ1317VNPJJ-S5; EQ5201GFJ6; CA1200PK2L7T3EA80; LZ1160LCMT; DFL1250A9; BJ5317ZNPJJ-S; CA1253P7K2L11T1E ; EQ1252GFJ;
|
SQ8SK3Q Lifting capability diagram
|
Working radius (m)
|
2.5
|
4.5
|
7
|
9
|
11.5
|
|
Lifting capacity (kg)
|
8000
|
4400
|
2500
|
1750
|
1100
|
& Due to improvements made to the product, data herein is subject to change without notice.
& Affected by the reproduction conditions, the pictures and data differ somewhat from the actual machine
