Items |
Unit |
Parameters |
| Total length | mm | 14300 |
| Total | mm | 2490/3390 |
| Total | mm | 3220 |
| Axle base | mm | 3600 |
| Rated work | m | 40 |
| Max. platform | m | 38.3 |
| Max.work range | m | 19 |
| Arm luffing range | ° | -12~+80 |
| Bent arm luffing range | ° | -65~+70 |
| Arm luffing time | s | 60 |
| Arm contraction time | s | 90 |
| Max.rotation speed | r/min | 0.8 |
| Max.tail swing | mm | 1400 |
| Platform size | mm | 1800×900×1150 |
| Platform rotation range | ° | 180 |
| Turntable rotation radius | mm | 2650 |
| Total weight under travel condition | kg | 18700 |
| Rated load | kg | 150 |
| Max. load | kg | 450 |
| Max.travel speed | km/h | 4.8 |
| Min. turning radius | m | 7 |
| Min.ground clearance | mm | 260 |
| Max. gradeability | % | 40 |
| Engine model | B3.3 Tier3 | |
| Rated engine power | kW/(r/min) | 63/(2600) |
| Solid tyre | 12.00-20/8.5 |
