Technical Specifications

Model	SQ4SK2Q	Unit
Max Lifting Capacity	4000	kg
Max Lifting Moment	8.40/10	T.M
Recommend Power	16	kw
Max Oil Flow of Hydraulic System	25	L/min
Max Pressure of Hydraulic System	20	MPa
Oil Tank Capacity	60	L
Rotation Angle	All Rotation
Crane Weight	1271/1396	kg
Installation Space	850	mm
Choice of Chassis	EQ1092FJ; EQ1092FJ1; EQ1092F3GJ1; EQ1081GJ12D5; DFL1120B; LZ1120LAPT; HFC1132KR1K3; EQ5121GFJ; HFC1083K103R1D; EQ1110GLJ3; EQ1120GLJ; EQ1168TLJ; BJ1122V4PBB-A1; BJ1158VKPFK-2

SQ4SK2Q Lifting capability diagram

Working radius (m)	2.10	2.50	3.00	7.93
Lifting capacity (kg)	4000	3120	2580	754

& Due to improvements made to the product, data herein is subject to change without notice.
& Affected by the reproduction conditions, the pictures and data differ somewhat from the actual machine
