Technical Specifications
|
Model
|
SQ14ZK4Q
|
Unit
|
|
Max Lifting Moment
|
35
|
t.m
|
|
Max Lifting Capacity
|
14000
|
kg
|
|
Recommend Power Needed At Recommend Oil Flow
|
32
|
kw
|
|
Max Oil Flow of Hydraulic System
|
63
|
L/min
|
|
Rated Pressure Of Hydraulic System
|
26
|
MPa
|
|
Oil Tank Capacity
|
220
|
L
|
|
Rotation Angle
|
(360°)All Rotation
|
?
|
|
Crane Weight
|
4800
|
kg
|
|
Installation Space
|
1300
|
mm
|
|
Choice of Chassis
|
BJ1317VNPJJ-S5; NXG1310D3ZEX
|
SQ14ZK4Q Lifting capability diagram
|
|
Working radius(m)
|
2.5
|
4.046
|
5.826
|
7.646
|
9.516
|
11.4
|
|
Lifting capacity(kg)
|
140000
|
8400
|
5478
|
4080
|
3148
|
245
|
& Due to improvements made to the product, data herein is subject to change without notice.
& Affected by the reproduction conditions, the pictures and data differ somewhat from the actual machine
