Technical Specifications

Main technical data in travel configuration
Category	Item		Unit	Parameter
Dimension	Overall length		mm	13430
	Overall		mm	3990
	Overall		mm	2500
	Wheel base	Axles 1 and 2	mm	5200
		Axles 2 and 3	mm	1350
	Tread	Front axle	mm	2035
		Rear axle	mm	1804
Weight	Weight with full load		kg	32900
	Axle load	Front axle	kg	7450
		Dual rear axles	kg	25450
Travel performance	Max. travel speed		km/h	85
	Min. turning diameter		m	≤24
	Approach angle		°	16
	Departure angle		°	9
	Braking distance(at 30km/h)		m	≤10
	Min. ground clearance		mm	290
	Max. gradeability		%	≥25
Main technical data for operation
Main performance	Rated working		m	53
	Rated load		kg	400
	Max. working radius		m	17
	Outrigger span(longitudinal×lateral)		m	6.45×6.0
	Elevating range		°	?3~80
Working speed	Boom deploying time		S	≤180
	Outrigger extending time		S	≤30
	Slewing speed		r/min	0~2
Fire-fighting performance	Water pump rated flow		L/s	65
	Water pump rated pressure		MPa	1.0
	Water monitor rated flow		L/s	50
	Water monitor rated pressure		MPa	≤1.0
	Water monitor rated reach		m	≥65

& Due to improvements made to the product, data herein is subject to change without notice.
& Affected by the reproduction conditions, the pictures and data differ somewhat from the actual machine
