Technical Specifications

Overall Dimensions(LXWXH)	7173×2366×3437 mm
Overall Weight	7300kg
Bucket Capacity	1.0 m3
Dumping	2825mm
Dumping reach	727 mm
Digger capacity	0.25-0.35 m3
Max. digging depth	4495 mm
Engine model	CumminsB4.5
Rated power	74KW
Rated speed	2200r/min
Overall displacement	4.5L
Min. fuel consumption	225g/KWh
Break out force	42KN

& Due to improvements made to the product, data herein is subject to change without notice.
& Affected by the reproduction conditions, the pictures and data differ somewhat from the actual machine
