Item
|
Parameter
|
Unit
|
|
|
|
Rated load
|
5
|
t
|
|
|
|
Bucket capacity
|
3
|
m³
|
|
|
|
Dumping
|
3090
|
mm
|
|
|
|
Dumping distance
|
1130
|
mm
|
|
|
|
Max.drawing force
|
170
|
kN
|
||
|
Max. traction
|
165
|
kN
|
|
|
|
Dimension
|
8185×3000×3465
|
mm
|
|
|
|
Operating weight
|
17200
|
kg
|
|
|
|
Boom lifting time
|
≤6.0
|
≤6.0
|
|
|
|
Total time of three devices
|
11
|
s
|
|
|
|
Wheelbase
|
3300
|
s
|
|
|
|
Min. turning radius (bucket outer)
|
6910
|
mm
|
|
|
|
Rated power
|
162
|
kW
|
|
|
|
Travel speed
|
I Gear (Forward/Backward)
|
0-11.5/16.5
|
km/h
|
|
|
II Gear (Forward)
|
0-38
|
km/h
|
|
|
|
Long boom parameter
|
|
|||
|
Item
|
Standard bucket
|
Coal bucket
|
|
|
|
Bucket capacity
|
2.7m³
|
3.5
|
|
|
|
Rated load
|
4.5t
|
4.0t
|
|
|
|
Dumping
|
3710mm
|
3550mm
|
|
|
|
Dumping distance
|
1180mm
|
1300mm
|
|
|
|
Dimension
|
8870×3000×3350
|
8870×3000×3465
|
|
|
|
Attachment parameter
|
|
|||
|
Attachment parameter—snow plow
|
|
|||
|
Pushing snow
|
3800
|
mm
|
|
|
|
Horizontal rotary angle
|
±38
|
°
|
|
|
|
Vibrating angle
|
±6
|
°
|
|
|
|
Obstacle crossing
|
0~150
|
mm
|
|
|
|
Rated power
|
162
|
KW
|
|
|
|
Attachment parameter-clamp
|
|
|||
|
Dumping
|
3241
|
|
|
|
|
Dumping distance
|
1902
|
|
|
|
|
Min. circle diameter and max. opening
|
|
|
|
|
|
Basic model
|
?800×1990
|
|
|
|
|
IV model
|
?430×2000
|
|
|
|
|
Attachment parameter-Sliding fork
|
|
|||
|
Fork folding angle
|
20
|
°
|
|
|
|
Attachment length
|
2053
|
mm
|
|
|
|
Attachment
|
2516
|
mm
|
|
|
|
Attachment
|
1200
|
mm
|
|
|
|
Fork teeth length
|
1200
|
mm
|
|
|
|
Attachment parameter-Side dumping
|
|
|||
|
Bucket
|
3000
|
mm
|
|
|
|
Dimension
|
8310×3040×3465
|
mm
|
|
|
|
Dumping (straight/side) dumping
|
2960/4125
|
mm
|
|
|
|
Dumping distance(straight/side) dumping
|
1272/105
|
mm
|
|
|
|
Lifting (straight/side) dumping
|
5407/6830
|
mm
|
|
|
